| Temperature（℃） | Pressure（MPa） |
| -240〜400 | 7.0 |
Maximum service temperatures for gasket metallic materials (for reference)■
| Material | Maximum service temperature （℃） |
| Lead | 100 |
| Brass | 260 |
| Aluminum | 260 |
| Copper | 400 |
| SUS304 | 427 |
| SUS316 | 816 |
| Pure iron | 538 |
| Low-carbon steel | 538 |
| Titanium | 1,093 |
| Material | Maximum service temperature （℃） |
| 5Cr-0.5Mo steel | 621 |
| SUS410 | 649 |
| Silver | 649 |
| Nickel | 760 |
| Monel metal | 816 |
| SUS321 | 816 |
| SUS347 | 816 |
| Inconel | 1,093 |
| Hastelloy | 1,093 |
Remarks Since the above maximum service temperatures are based on air with a certain constant temperature, they vary to a great extent depending on the type of liquid, pressures and mode of use.
